Double DC 618

Double DC 618

Contact us for price

Location:Čestlice, Czechia

orCall +420 222 512 626

Description

The Duplo DC-618 is the successor to the proven DUPLO DC 616 Pro model. It is an ideal solution for small series production of digital printing. Eliminates white borders and prevents toner cracking on digitally printed color documents. This device can create up to 6 longitudinal cuts, 30 cross cuts and 20 big cuts per pass at a speed of up to 23 sheets / min. This increases the efficiency and automation of finishing equipment. It offers fully automatic settings, fast transitions and a wide range of applications - greeting cards, invitations, brochures, book covers, photos, and business cards without the need for additional modules. The DC-618 comes standard with a new generation of PC Controller software for easy job setup using a PC and CCD sensor, which allows you to recall any job settings stored in the device's memory by reading a printed barcode. DC-618. The machine can be retrofitted with a programmable perforation unit Eliminates white edges and prevents toner cracking Performs up to 6 alloys, 30 cuts and 20 big in one pass Part of PC Controller software for easy work setup Built-in CCD scanner for reading barcodes and license plates Can be expanded with a programmable perforating unit APPLICATIONS: business cards, greeting cards, postcards, photos, tickets and much more Optional options: Programmable perforation unit Plastic articulated computer holder Computer

Specifications

ManufacturerDuplo
ModelDC 618
ConditionNew
TypeNew
Loader capacity100 mm
Paper weight110-400gsm
Min. paper format210 mm x 210 mm
Minimum output format50 x 48 mm
Max. paper size330 mm x 750 mm (1000 mm option)
Speed max.23 sheets / min according to the cut application
Type of loadingautomatic vacuum belt
Longitudinal sectionsup to 6 (rotary knives)
Cross sectionsup to 30 / sheet (knife)
Bigy up to 20 / arch(3 setting levels)
Max. paper format330 mm x 750 mm (1000 mm option)
